ERW Welded Carbon Steel Tube with En 10219 ASTM A500

Detailed Description:ProductElectric Resistance Welded Steel PipeUsageUsed for low pressure liquid delivery, such as

Detailed Description:

Product Electric Resistance Welded Steel Pipe
Usage Used for low pressure liquid delivery, such as water, gas, and oil. Oil drilling and machinery manufacturing, etc.
Standard API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, JIS G3452, BS1387
Certificate API 5L PSL1/PSL2, API 5CT, CE, ISO
Out Diameter 21.3mm -660.4mm
Wall Thickness 1.5mm-25.4mm
Length 1-12m or as customers required
Steel Grade
API 5L GR B, X42,X46, X56, X60,X65,X70,X80
ASTM A53 GR A, GR B, GR C
EN S275, S275JR, S355JRH, S355J2H
GB Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555
Surface Treatment Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating, Bitumen Coating, Black  painting or as per customer's requirement
        Chemical Element Composition (%)
GB ASTM BS C Mn Si S P
Q195 - A285M Gr.B S185 0.06~0.12 0.25~0.5 ≤0.30 ≤0.040 ≤0.035
Q215 A A285M Gr.C 040A12 0.09~0.15 0.25~0.55 ≤0.35 ≤0.050 ≤0.045
B A573M Gr.58 - ≤0.045
Q235 A A570 Gr. A S235JR 0.14~0.22 0.30~0.65 ≤0.36 ≤0.050 ≤0.045
B A571 Gr. D S235JRG1 0.12~0.2 0.30~0.70 ≤0.045
C A283M Gr.D S235JRG2 ≤0.18 0.35~0.80 ≤0.040 ≤0.040
D - - ≤0.17 ≤0.035 ≤0.035
Q345 A A572 Gr.50 - ≤0.20 1.00~1.60 ≤0.55 ≤0.045 ≤0.045
B 50B ≤0.040 ≤0.040
C 50C ≤0.035 ≤0.035
D 50D ≤0.18 ≤0.030 ≤0.030
